The New Formlabs Studio Ecosystem Is Coming to Voxel Factory
Voxel Factory will sell the new Formlabs Studio ecosystem. We’re excited to bring our community a connected resin 3D printing workflow built around Form Studio 1, Form Studio Wash+Cure, and the new Alpha Resins.
From detailed models to functional prototypes, the Studio ecosystem brings printing and post-processing together, helping you move from a digital design to a finished part with less trial and error.
Explore the Formlabs Studio Ecosystem
Meet Form Studio 1
Form Studio 1 is a masked stereolithography (MSLA) printer designed to make professional resin printing more accessible. Automatic resin dispensing and validated material settings simplify setup, while intelligent controls monitor resin temperature, resin level, print forces, and leveling during printing.
A custom lens array and 28 LEDs deliver uniform illumination. Release Texture V2 and a flexible film tank reduce peel forces to support faster printing while preserving fine detail and smooth surfaces. According to Formlabs, most prints finish in under two hours, though print time varies with the model, material, and settings.
Prepare, print, and stay connected
Import your design into PreForm and use one-click print preparation, or adjust orientation and supports yourself. Real-time printability checks help flag issues before you start.
Once the cartridge, tank, and build platform are in place, automatic resin dispensing handles resin delivery. The Form Mobile App and free Dashboard software let you start, queue, and track prints remotely, and an integrated camera lets you view progress in the app.
Wash and cure in one workflow
Form Studio Wash+Cure takes care of the next stages after printing. Wash parts on or off the build platform, then flex the quick-release platform to release parts without scraping.
Let parts air dry completely before curing. Remove the light-touch supports, then use the curing turntable to bring parts to their final mechanical properties. Finished parts can be used as-is or further sanded, coated, and painted.
A new family of Alpha Resins
Shown: Alpha Clear, White, Grey, Black, and Model Resins, alongside Tough 1500 Resin V2.
The Alpha Resin family offers options for different projects:
Alpha Model Resin
A fully matte, neutral surface that brings out small details and textures and paints beautifully.
Alpha Fast Resin
Designed for rapid prototyping and iteration, with advertised print speeds up to 130 mm per hour.
Alpha Clear Resin
Optical clarity, crisp features, and smooth surfaces for see-through parts.
Alpha Black, Grey, and White Resins
Rich matte colours and dimensionally accurate surfaces for display-ready parts and assemblies.
Formlabs provides validated settings for its materials, and Form Studio 1 also supports third-party resins without a licence fee.
Low-emission printing with a defined setup
According to Formlabs, Alpha Resins achieve UL GREENGUARD Gold certification for low VOC emissions during printing when used on Form Studio 1 with the VOC Extractor. That certification applies to this specific printing setup, not to every resin or printer configuration. Follow the material’s handling instructions and safety documentation when printing and post-processing.
Form Studio 1: Technical specifications
- Technology: Masked stereolithography (MSLA)
- Build volume: 200 × 125 × 235 mm
- Layer thickness: 25–250 µm
- Average print speed at 100 µm layer height: 40 mm/hour
- Maximum print speed: 130 mm/hour
- Printer dimensions: 34.2 × 31.5 × 50.2 cm
- Printer weight: 14.3 kg
Coming to Voxel Factory
We look forward to helping our customers explore the Studio ecosystem, whether you’re iterating on a design, producing detailed models, or creating parts for your next project.
Ready to explore the Formlabs Studio ecosystem? Contact us for pricing and availability. Our team can help you choose a setup for your application.
Contact Voxel Factory
Have questions about the Formlabs Studio ecosystem? Contact our team to discuss your project and find the right setup for your needs.
